Admore AB409-U — 13A 1-Gang Switched Socket with USB-A + USB-C, Single-Pole Rocker, Gloss Black Screwless Plate (Metal Series: Black Nickel)

Overview The Admore AB409-U is a premium 13-amp single-gang switched socket from the Metal Series: Black Nickel line, finished in a screwless gloss-black stainless-steel plate. USB charging The on-plate label printed next to the USB ports reads "2.1A — 5V". The two USB ports (1× USB-A + 1× USB-C) share a single 5-volt, 2.1-ampere supply between them — meaning each port can deliver up to 2.1 A on its own, but when both ports are used together the total output remains 5 V 2.1 A shared between the two devices. Switching & outlet A side-mounted single-pole rocker switch isolates the live conductor to the outlet when in the off position. Both the rocker and the outlet insert are finished in matt black against the gloss-black plate. Construction The faceplate is pressed stainless steel with a glossy black-nickel-style electroplated finish. The screwless design hides the fixing screws beneath the plate for a clean architectural look. Internally the unit uses copper pillar terminals with captive M3.5 screws — captive screws stay attached to the terminal as you wire, which speeds installation and prevents lost hardware behind the back-box. Installation Minimum back-box depth is 25 mm. Terminals accept up to 2× 2.5 mm² stranded copper conductor per terminal. The earth terminal is captive and clearly marked. Electrical specifications Rated current: 13 A Rated voltage: 220–240 V AC Frequency: 50 Hz USB output: 5 V, 2.1 A shared between USB-A + USB-C Switch: Single-pole rocker (SP) IP rating: IP20 (indoor) Insulation class: Class I (earthed) Operating temperature: −5 °C to +40 °C Box contents 1× AB409-U switched socket with USB · 2× black-matched fixing screws · Installation guide
